US Products Catalog 2015-2016 •
5
StandardWatt Density Models
ODL
Options
1
Wall length = Length - 3/8" (9.5 mm).
2
These 2-wire relays with transformer can't supply of 3-wire low voltage thermostats.
3
"Off" position.
4
For the U.S. only: The nominal current of the unit must not exceed 80% of the capacity of the disconnect.
Add "BL" for white, "CM" for metallic charcoal.
Optional colors shown in the color chart section are available upon request.
Other voltages available upon request.
LowWatt Density Models
Watts
Watts
240/208V
Product #
Price
Length
1
Weight
120V
208V
240/208V
277V
in.
mm lb
kg
300
300/225
ODLU0302
ODLU0308
ODLU0300
-
246.00
24
5/8
625
7.4
3.4
500
500/375
ODLU0502
ODLU0508
ODLU0500
ODLU0577
256.00
29
1/2
750
8.5
3.9
750
750/563
ODLU0752
ODLU0758
ODLU0750
ODLU0777
280.00
39
1/2
1004
10.7
4.9
1000 1000/750
ODLU1002
ODLU1008
ODLU1000
ODLU1077
302.00
49
13/16
1265
13.0
5.9
1250 1250/938
ODLU1252
ODLU1258
ODLU1250
ODLU1277
323.00
59
1/4
1506
15.1
6.9
1500 1500/1125
ODLU1502
ODLU1508
ODLU1500
ODLU1577
342.00
68
1727
17.0
7.7
1750 1750/1313
-
ODLU1758
ODLU1750
ODLU1777
377.00
77
5/16
1964
19.1
8.7
2000 2000/1500
-
ODLU2008
ODLU2000
ODLU2077
399.00
86
1/8
2187
21.0
9.6
2250 2250/1688
-
ODLU2258
ODLU2250
ODLU2277
420.00
94
15/16
2412
23.0
10.5
2500 2500/1875
-
ODLU2508
ODLU2500
ODLU2577
441.00
104
1/16
2644
25.0
11.4
Watts
Watts
240/208V
Product #
Price
Length
1
Weight
120V
208V
240/208V
277V
in.
mm lb
kg
300
300/225
ODLU0302-750 ODLU0308-750 ODLU0300-750 ODLU0377-750
256.00
29
1/2
750
8.5
3.9
500
500/375
ODLU0502-1004 ODLU0508-1004 ODLU0500-1004 ODLU0577-1004
280.00
39
1/2
1004
10.7
4.9
750
750/563
ODLU0752-1265 ODLU0758-1265 ODLU0750-1265 ODLU0777-1265
302.00
49
13/16
1265
13.0
5.9
1000 1000/750
ODLU1002-1506 ODLU1008-1506 ODLU1000-1506 ODLU1077-1506
323.00
59
1/4
1506
15.1
6.9
1250 1250/938
ODLU1252-1727 ODLU1258-1727 ODLU1250-1727 ODLU1277-1727
342.00
68
1727
17.0
7.7
1500 1500/1125
ODLU1502-2187 ODLU1508-2187 ODLU1500-2187 ODLU1577-2187
399.00
86
1/8
2187
19.1
8.7
1750 1750/1313
-
ODLU1758-2412 ODLU1750-2412 ODLU1777-2412
420.00
94
15/16
2412
21.0
9.6
2000 2000/1500
-
ODLU2008-2644 ODLU2000-2644 ODLU2077-2644
441.00
104
1/16
2644
23.0
10.5
2250 2250/1688
-
ODLU2258-2644 ODLU2250-2644 ODLU2277-2644
441.00
104
1/16
2644
23.0
10.5
Product #
Price
Description
Factory
Installed
Kit
ODL-DIS20
4
82.00
Disconnect switch, double-pole, 20A at 277V max.
3 3
ODL-HA
15.00
Linear high-limit temperature control for high altitude (3000 ft. to 8200 ft.)
3
-
ODL-R-347
92.00
Single-pole relay, coil 24V, without transformer: 22A at 120V, 208V, 240V - 18A at 347V
3 3
ODL-R-600
123.00
Single-pole relay, coil 24V, without transformer, 10A at 600V
3 3
ODL-RT-120
2
205.00
Single-pole relay, coil 24V, with transformer, 25A at 120V (2-wire only)
3 3
ODL-RT-208
97.00
Single-pole relay, coil 24V, with transformer, 22A at 208V
3 3
ODL-RT-240
97.00
Single-pole relay, coil 24V, with transformer, 22A at 240V
3 3
ODL-RT-277
97.00
Single-pole relay, coil 24V, with transformer, 19A at 277V
3 3
ODL-RT-347
154.00
Single-pole relay, coil 24V, with transformer, 18A at 347V
3 3
ODL-RT-600
2
154.00
Single-pole relay, coil 24V, with transformer, 10A at 600V (2-wire only)
3 3
ODL-TB6
43.00
Single-pole bi-metal thermostat: 25A at 120V, 208V, 240V - 10A at 347V, 600V
3 3
ODL-TB26
3
51.00
Double-pole bi-metal thermostat: 25A at 120V, 208V, 240V - 10A at 347V, 600V
3 3
ODL-TB6-AV
61.00
Single-pole bi-metal tamperproof thermostat: 25A at 120V, 208V, 240V - 10A at 347V, 600V
3 3
ODL-TB26-AV
3
72.00
Double-pole bi-metal tamperproof thermostat: 25A at 120V, 208V, 240V - 10A at 347V, 600V
3 3
ODL-TRIAC-347
102.00
Single-pole electronic relay, coil 24V, without transformer, 15A at 347V max.
3 3
ODL-TRIAC-347T
154.00
Single-pole electronic relay, coil 24V, with transformer: 15A at 208V, 240V, 347V
3 3
ODL-TRIAC-600
205.00
Single-pole electronic relay, coil 24V, without transformer, 6A at 600V max.
3 3
